With the input from some of the world’s renowned enthusiasts, BitFenix has developed the Shogun to be an extremely desirable chassis with many novel features. Carrying on the theme of simplicity from the previous ‘Shinobi’ case, Shogun is the newest flagship design model from BitFenix. Be it performance or looks, Shogun is the best of both worlds.
Dual Tempered Glass
BitFenix Shogun features two high-quality tempered glass on either sides to showcase the beautiful components. With semi-tinted and fully tinted tempered glass you can hide the cables behind the motherboard tray. The semi-tinted glass can showcase the components while giving it a light shade to emphasise the premium looks.
Thick Aluminium Panels
To add to the premium elegant look of the Shogun, the top and bottom is wrapped around with thick curved aluminium panels. This gives strength as well as a clean look while keeping the dust away from the PSU.
BitFenix Quick Custom EATX
Thanks to ‘BitFenix Quick Custom Design Technology’, the Shogun sports a modular design for high-end hardware. BitFenix Shogun supports up to EATX motherboards with a customizable motherboard tray for easy cable routeing. The included Quick Custom EATX Shield can be used only when an EATX motherboard installed to route cables neatly. The chassis is designed with 25mm of space behind motherboard tray and plenty of cable tie spots for cable management
Quick Custom Cooling
Shogun can host up to radiators of size 360mm or 280mm on the top panel, 280mm or 240mm on the front and 140mm or 120mm on the rear panel. These can be easily accessed with snappy front and top panels that also comes with dust filtered ventilations that can be easily washed along with the panel itself.
Quick Custom HDD
With the ‘Quick Custom Design’, the hard drive cages supporting up to 6 HDDs or 8 SSDs can be easily removed to accommodate any other component or moved to any location on the mounting rails to satisfy your needs.
GPU Safe
BitFenix Shogun comes with three new ‘GPU Safe’ Graphic card supports. They can be easily configured to support various GPU models. This removes any possible damage that could happen to the electronic components due to bending.
Quick Custom SSD Chroma
Along with the Shogun comes two all new SSD Chroma Modules certified by “ASUS Aura”. Thanks to quick custom design, the LED strip inside the Chroma modules can be easily adjusted to light up the SSD from side or bottom. The whole bracket can be easily and quickly removed thanks to ‘BitFenix Quick Custom Design.
| Colour | Black |
| Materials | Aluminium │Tempered Glass │SECC Steel │ABS |
| Chassis Type | Super Mid-Tower |
| Motherboard | E-ATX │ ATX │ M-ATX │ Mini-ITX |
| CPU Cooler | Up to 175mm Height |
| Graphic Card Length | Up to 410mm |
| Power Supply Length | Up to 250mm |
| Storage Capacity(5.25″ODD) | 0 |
| Storage Capacity (3.5″ HDD) | 6 |
| Storage Capacity (2.5″ HDD) | 6 + 5 |
| Cooling Capacity (Front) | Up to 140mm x 2 or 120mm x 3 (2x120mm Included) |
| Cooling Capacity (Rear) | 120mm x 1 (Included) │ 140mm x 1 |
| Cooling Capacity (Top) | Up to 140mm x 2 or 120mm x 3 |
| Radiator Capacity (Front) | Up to 280mm x 1 or 240mm x 1 |
| Radiator Capacity (Rear) | 120mm x 1 │ 140mm x 1 |
| Radiator Capacity (Top) | Up to 360mm x 1 or 280mm x 1 |
| Front I/O port | USB 3.0 x 2 │ USB 2.0 x 2 │ HD Audio MIC & Headphone |
| Dimensions (WXHXD) | 250 x 565 x 525 (mm) |
| Weight | 14.15kg (net)│16.34kg (gross) |
| Highlights | Elegant Aluminium Design │ Dual Tempered Glass Side Panel │ Quick Custom storage design │ Quick Custom SSD Chroma │ Quick Custom EATX Shield │ BitFenix Chroma Control and SSD Chroma │ Advance design GPU Safe │ Support Graphic Card Length up to 410mm │ Up to 25mm Cable management Space │ 360mm Radiator Support at Top │ 3 pre-installed Fans |
